【 Scope Of Application 】

 Used for the closure of residual ends or incisions in digestive tract reconstruction and organ resection surgeries.

【 Usage 】

1. Check the sterile packaging of the equipment, confirm that there is no damage, and then open the packaging to remove the equipment.

2. Remove the red nail compartment protective cover from the instrument.

3. Place the instrument at the site that needs to be sutured, push the positioning needle forward to correctly enter the positioning hole; Attention: If the positioning needle cannot enter the positioning

hole correctly, please carefully check whether the installation of the component is correct.

4. During the process of closing the instrument with a single firing handle, please always maintain a good view and organize the tissue to avoid surrounding tissues or organs being trapped inside the

instrument. At the same time, check whether the arrow "↑" on the positioning rod push plate handle is aligned with the black marking line on the fixed handle; If the alignment is not correct, push the

positioning needle forward to align it.

5. Double fire the handle, clamp the tissue to be removed, and return the handle to its original position.

6. Firing the handle again will complete the tissue suturing (grip the handle tightly to the bottom).

7. Before exiting the instrument, the excess tissue that needs to be removed can be removed with a surgical knife.

8. Press the reset button to exit the device.

9. If components need to be replaced, first confirm that the firing handle is reset, pull the positioning rod push plate handle to the bottom, and remove the previously used components; Take out the

spare components from the sterile packaging, install them onto the instrument, check if the positioning needle can enter the positioning hole, pull the positioning rod to push the positioning needle

up and down, indicating that the components are installed in place. Remove the red protective cover on the components and repeat steps 3-8.
